Schuylkill Navigation Maps
Reading Area Community College

The Twelfth Reach
above Blue Mountain Dam
To view an image, click on the thumbnail. Use your browser's back button to return. Please note the file sizes.
Large Maps
Map #
File Sizes
  Plan & sections 12-2 12-2 Lock #33 350k
Plan & sections 12-3 12-3 Lock #17 307k
Plan 12-10 12-10 Coal chutes at Port Clinton 209k
Plan & sections 12-101 12-101 Hummel's Dam 184k
Plan 12-102 12-102 Railroad at Port Clinton Dock 212k
Details of scales & chutes 12-104 12-104 Proposed new coal transfer landing, Port Clinton 110k
Alignment & profile 12-105 12-105 Proposed new coal transfer landing, Port Clinton 139k
Small Maps Map # Description File Sizes
  Water levels 12-S1 12-S1 Lord's Dam and Hummel's Dam 152k
Profiles & sections 12-S101 12-S101 Hummel's Dam 80k
Plan 12-S104 12-S104 Hummel's Dam - position of cribwork after flood 110k
Plan, elevations, sections & details 12-S105 12-S105 Changes in chute, Port Clinton 151k
Plan 12-S106 12-S106 Canal from Blue Mountain Dam to Port Clinton 133k
Plan, elevations & sections 12-S107 12-S107 Extension of Port Clinton shipping landing 247k
Plan 12-S108 12-S108 Canal form Kernsville Dam to Port Clinton 161k
Plan 12-S109 12-S109 Location of tracks, Port Clinton 142k
Plan 12-S110 12-S110 River below Port Clinton 69k
Plan 12-S113  12-S113 Typical silt dump  65k
