Schuylkill Navigation Maps
Reading Area Community College

The Second Reach
Manayunk to Flat Rock Dam
To view an image, click on the thumbnail. Use your browser's back button to return. Please note the file sizes.
Large Maps
Map #
File Sizes
  Plan 2-13 2-13 Inlet of Manayunk Canal & property just upstream 110k
Map 2-19 2-19 Manayunk and center city 131k
Plan 2-22 2-22 Lower half of Manayunk Canal 150k
Plan & sections 2-102 2-102 Repairs to break in Flat Rock Dam 133k
Section 2-104 2-104 Proposed power house at Manayunk 173k
Section 2-108 2-108 Railroad track and canal with bridge above 123k
Elevation 2-116 2-116 South elevation of new feeders 83k
Record 2-123 2-123 Height of water at Flat Rock Dam (January 1880 - January 1889) 122k
Plan 2-149 2-149 Soundings in canal at Phila Paper Mfg. 196k
Plan & sections 2-165 2-165 Proposed new dam at Flat Rock 195k
Small Maps Map # Description File Sizes
  Profile 2-S11 2-S11 Proposed conduit from Flat Rock to Fairmount 172k
Plan & details 2-S12 2-S12 Proposed raising of bridge at Fountain Street 86k
Plan 2-S13 2-S13 Proposed rebuilding of Flat Rock Dam 119k
Plan 2-S27 2-S27 Bridge crossing at Green Lane, Manayunk 107k
Plan 2-S101 2-S101 Canal & path at Picton Mills, Manayunk 73k
Plan 2-S104 2-S104 Canal & bridges, Inquirer Paper Mills, Manayunk 92k
Plan 2-S111 2-S111 Rector Street sewer at Manayunk Canal 87k
Plan 2-S115 2-S115 Upstream end of Manayunk Canal 94k
Plan, section and elevation 2-S119 2-S119 Concrete wing walls at end of discharge pipe 58k
 Plan 2-S128 2-S128   Location of iron pipe (nixon to canal) 65k
